Fire roof sliding door Jalusi OHD-C EI(1) 60 / EI(2) 90 / EW 90

The fire roof sliding door OHD-C EI(1)60/EI(2) 90/EW90, is tested and certified against these 3 fire classes. The slatted mat of the fire roof sliding door consists of fire-resistant composite material and the color is an off-white structure colour. Guide rails are in galvanized steel and the gate is equipped with a gravity closing 400V failsafe motor. The delivery includes a control cabinet that takes care of the signals going in and out to ensure a safe and secure function. Control via buttons on the control cabinet or via external control as desired. In the case of impulse control, light curtains are supplied as pinch protection. In the case of holder control/dead man’s grip in connection with the door, no pinch protection is required. The control cabinet has built-in batteries that keep the fire roof sliding door open in the event of a power failure. The time for opening depends on the status of the batteries and the ambient temperature. The gate is supplied with optical and acoustic alarm sensors to be mounted on both sides of the opening. The fire roof sliding door is mounted only outside the so-called opening. wall mounting.

Maximum width: 5,175 meters
Maximum height: 6,967 meters
Maximum area: 23.5 m²
